DesignCAD 3d Max - Easy-to-Use 2D/3D CAD Software

DesignCAD 3D Max 2022 Upgrade from any DesignCAD 2D

Array

$149.99
Order form
Quantity
DesignCAD 3D Max 2022 Upgrade from any DesignCAD 2D

Product Info

Versatile 2D/3D CAD solution

DesignCAD 3D MAX is an easy-to-use 2D/3D CAD software suitable for users new to CAD,hobbyists,makers and DIYers. DesignCAD allows you to create high-quality designs, simple renders and animations. The latest release of this award-winning software supports AutoCAD drawing files, includes new 2D Drafting enhancements, 3D printing and expanded interoperability.

Key Features

checkmark iconVersatile 2D/3D CAD Solution

checkmark iconPrecision 3D Surface Modeling

checkmark icon3D Printer Support with STL file Import/Export

checkmark iconReal-Time OpenGL Rendering

checkmark iconAnimation & Walkthroughs

checkmark iconBasicCAD Scripting & OLE Automation

New Features
Related Product

Key Features

Versatile 2D/3D CAD Solution

Give depth to a 2D object to create a 3D object or use Design CAD 3D Max’s design and drafting tools palette to create versatile designs.

Precision 3D Surface Modeling

Drafting Assistant will help you layout your design or import existing files for easy editing. With intuitive design tools, novice designers can quickly create precision 3D surface designs.

3D Printer Support with STL Support

The 3D print tool allows you to pass a TurboCAD STL file to 3D printer control software and print/manufacture 3D models of your project.

Real-Time OpenGL Rendering

The Open GL rendering engine provides live shaded views which you can rotate, pan or draw in shaded mode. Perform solid operations such as subtract or copy and get their results in shaded view.

Animation & Walkthroughs

View the animation of your 3D model by using the walkthrough feature and examine it to figure out any required modifications.

Drawing Compare

Drawing Compare will perform a visual comparison of two BMP images. Most effective when working collaboratively on a project.

New Features

New Selection Tool

User can now select the whole drawing just by selecting any portion. Select right to left updated to select the entire object if any portion is selected. Select left to right stays as it is, i.e., select the entire object if and only if the whole object is inside selection box.

New Icon Size

A new medium icon size (24x24) has been introduced using Icon slider inside View Option dialog. Previously, only small(16x16) and large(32x32) icon sizes were available.

Pre-defined Views

9 different pre-defined views have been added to the DesignCAD 2022 version, that can be applied on the drawing window. Those 9 views are: Front View, Top View, Bottom View, Right View, Left View, Perspective View, Isometric View, Parallel View, and Trimetric View.Option to select pre-defined views is added in View tab inside Classic and Ribbon Menu.

Block Editor Mode in Ribbon

Just like classic menu, we can use Ribbon menu to save edits while in block editor mode.Separate group for Block Editor/Insert Manager is created in File Tab of Ribbon which contains options to save and exit the block editor mode once the block is edited.

DesignCAD Reviews

DesignCAD User Gallery

System Requirements

DesignCAD 3D Max is delivered in a 64-bit version to take full advantage of your hardware’s available computer memory to load, process, and render CAD files. A 32-bit version is also available if required by your hardware.

64-bit System Requirements:

Microsoft Windows 11, Windows 10, Windows 8* 64-bit, Windows 7 (64-bit), 4GB RAM; 750 MB free hard drive space

32-bit System Requirements:

Microsoft Windows 10, Windows 8*, Windows 7, 4GB RAM; 750 MB free hard drive space

*DesignCAD is designed for desktops or laptops that meet the indicated system requirements. Windows RT technology for use on tablets is not supported.

Recommended:

Your experience with DesignCAD will be greatly enhanced with a newer generation, higher speed CPU; 4+ GB RAM; Large display resolution and graphics support; Internet connection for online features and content.TurboCAD Deluxe will be greatly enhanced with a newer generation, higher speed CPU, 8+ GB RAM.

Buy Your DesignCAD Product Now

Find the DesignCAD version that best fits your needs

DesignCAD 2D

$6999

  • 2D Drawing, Editing & Modifying
  • AutoCAD® (DXF, DWG & DWF) File Compatibility
  • Architectural Tools
  • 2D Symbols
  • -
  • -
  • -
  • -
  • -
